    Automatic Programming CNC Roll Turning Lathe Machine For Variety Of Materials Roll 500mm

    Ask Lasest Price
    Brand Name : Baishun
    Model Number : CK8465
    Certification : ISO; CE
    Price : negotiation
    Supply Ability : 20 SETS PER MONTH
    Delivery Time : 30 days
    • Product Details
    • Company Profile

    Automatic Programming CNC Roll Turning Lathe Machine For Variety Of Materials Roll 500mm

    CNC roll turning lathe machine CK8450 model 500mm roll lathe cnc turning machine


    Good Discription:


    CK84 Series CNC Roll lathe using Siemens 802D CNC,servo motor drive.The machine tool designed to fully analyze the ATOMAT Italy, Germany HERKULES's roll lathe technical performance indicators, new forms of mechanical structure, at the same time drawing on well-known domestic machine tool companies of similar experiences.The machine tools suitable for a variety of materials roll, roll the compound of the Central and rough, finishing.
    4,the overall use of machine tool guide rail+1 auxiliary guide for a high-rigidity machine tool provides a reliable guarantee.
    Saddle-bed machine tools, mobile tool using high-rolling rigid rail support and enhance the stability of the machine tools and high-rigid system, as well as sensitivity to ensure that the machine's overall accuracy of intergrated processing, machine-wide stainless steel rail protection.Frequency use spindle motor power 30KW,stepless speed regulation.
    Machine tools equipped with special software, interactive operating system can cylindrical roller,pass automatic programming, thereby reducing the cumbersome programming work, improve efficiency.


    Item

    Roll the
    maximum
    diameter

    Roll the
    maximum
    length

    Center
    High

    Machine tools in
    the form guide

    Width of the
    machine
    tool guide

    The largest
    weight of
    the workpiece

    CK8450HΦ500mm2500/3500mm400

    2+3 rolling in a
    strsight line guide

    8203.5T/5T
    CK8450Φ500mm2500/3500mm4004+1overall guide8203.5T/5T
    CK8465Φ500mm2500/3500mm4504+1overall guide11005T/8T
    CK8485Φ500mm2500/3500mm500

    4+1overall guide
    uide

    14008T/12T

    Item

    Spindle
    box
    spindle
    hole cone

    Chuck with Spindle

    Tailstock
    spindle
    hole core

    Tailstock
    sleeve
    trip

    Spindle
    Speed

    The main electrical
    power

    Face Chuck
    Maximum
    torque
    CK8450HNO.80500mm(Four long claw)Mo’s6#200mm5-350rpm

    30KW Frequency
    spindle motor

    12KN.m
    CK8450NO.80500mm(Four long claw)Mo’s6#200mm5-350rpm

    30KW Frequency
    spindle motor

    12KN.m
    CK8465NO.80630mm(Four long claw)Mo’s6#200mm5-350rpm

    30KW Frequency
    spindle motor

    12KN.m
    CK8485NO.80800mm(Four long claw)Mo’s6#200mm3-350rpm

    49KWKFrequency
    spindle motor

    16KN.m
